STAR FLASH HELMET

FEATURES - TRACKMASTER

- ECE R22.06 Approval.
- Front filtration system.
- Double ring closure.
- Fiberglass casing.
- Removable and washable interior.
- Interchangeable visor.

WARNING

Read these instructions for use carefully and completely for your own benefit.
safety, especially the safety instructions.
After suffering a fall or a hard blow to the helmet, it is no longer guaranteed.
Its protective function is fully utilized. The absorption of forces is achieved through the
Total or partial destruction of the outer and/or inner hull. This damage,
especially those suffered by the inner hull covering, cannot be observed
at first glance. Therefore, as a general rule, the helmet should be replaced after having
suffered a fall or a hard blow. Discard the old helmet for safety reasons.
Do not place the helmet too close to the exhaust pipe. High temperatures
can cause damage to it.
The safety labels and stickers must not be removed.

NO HELMET CAN PROTECT THE USER FROM ALL IMPACTS.

- When purchasing a helmet, please note the following:

· The helmet fits your head perfectly.
· It cannot be turned sideways.
• The forward and backward movements of the helmet are transmitted
directly onto the scalp.
· The helmet will only be able to perform its protective function if it is of the
correct size.

The helmet must be worn at all times while riding a motorcycle.
- For maximum safety, it is important that the helmet fits the user.
- The double D-ring closure MUST be properly adjusted to secure the
helmet firmly during use.
- Follow these steps for proper closure:
1. Pass the chin strap through the eyelets of both double D-rings.
2. Roll it back and pass it through the top ring with the red tab.
3. Tighten the strap firmly until it is comfortable and secure.
4. Press and fasten the automatic button to control excess strap.

ADJUSTMENT

Choosing the correct helmet size is very important:
-Seek advice at a specialist store.
-Never use a helmet that is too big. If, when holding the helmet in your hands, it
If you can move your head freely inside, it will be too big.
-Do not use a helmet that is too small. If you feel uncomfortable or painful pressure.
-Once the adjustment strap is closed, the helmet should not rotate, leaving the chin at the
view or leave.

REPLACE THE VIEWFINDER

To replace the viewfinder, follow these steps:
- Unscrew the side screws completely.
- Do not remove the plastic discs. If the discs are removed, they must be placed
placed back in the same position: large disc on the helmet shell
aligning the slots and the small disc between the screw and the viewfinder.
- Install the new viewfinder.
- Screw the screws back in.

OPEN VENTILATION

To open the chin guard's internal ventilation, slide the tab upwards.
(closed) or downwards (open).
If the helmet has external vents, they will be opened
The same way, but in this case, upwards (open) downwards (closed).

HOW TO DISASSEMBLE INTERIORS

When you want to remove the inside of the helmet for cleaning, you must follow these steps:
These steps:
- Release the snap fasteners on the side pieces.
- Detach these pieces from the base of the hull.
- Once the side pieces are removed, detach the top piece from the bead.
of the opening and the base of the helmet.
You can now proceed to clean the inside of the helmet. It is recommended to use
a mild soap to prolong the life of the materials.

USE AND MAINTENANCE

-To clean the helmet, use a mild soap solution or a special product for
helmets with lukewarm water, NEVER hot.
-To dry the helmet, it is advisable to let it air dry at room temperature. Do not use
a heat source for drying the helmet.
-Do not expose the helmet to strong sunlight in an enclosed area without ventilation.
-The internal or external structure of the helmet must not be modified for any reason, since
It can be cut, drilled, varnished or painted.

To learn more about the product, please visit the following link.
